Horizontal Laminar Flow Cabinet

An inoculation cabinet for microbiological and bacteriological work: air is blown into the chamber from the rear panel, and the front is open.

Features

Air is blown into the chamber from the rear panel; there is no sash and the front is open.
Room air passes through a coarse pre-filter, a carbon filter and a HEPA filter to create a sterile working space inside the cabinet.
The HEPA filter retains 99.998% of particles; its 2,000-hour service life is tracked by an hour counter.
A UV lamp and a daylight lamp are fitted as standard.
The body and all panels are made of galvanised sheet steel, coated with acid-resistant epoxy paint and oven-cured at 200 °C.
The work surface is grade 304 stainless steel and the side panels are fixed safety glass.
The front panel carries a 220 V 16 A earthed socket, daylight and UV lamp switches, a fan speed switch, a fuse box and the HEPA filter hour counter.
A tap for LPG or a similar flammable gas, an airflow alarm and a VAV control unit can be added as options.
Supplied as a benchtop unit as standard; an optional separate stand lets it be used independently of a bench.

Airflow: Horizontal (from the rear panel into the cabinet)
Front sash: None (open front)
Filters: Coarse pre-filter, carbon filter, HEPA filter
HEPA filter efficiency: 99.998%
HEPA filter service life: 2,000 hours (tracked by an hour counter)
Fan capacity: 960 m³/h (±10%)
Body: Galvanised sheet steel, acid-resistant epoxy paint, oven-cured at 200 °C
Work surface: Grade 304 stainless steel
Side panels: Fixed safety glass
Lighting: UV lamp and daylight lamp
Electrical: 220 V 16 A earthed socket
W × D × H (mm): 1300 × 750 × 1300
Total height on stand: 2050 mm (with 750 mm stand)
Special widths: 1000 mm and 1800 mm
Installation: Benchtop (standard) or on a separate stand
